LUXEON Sun Plus 5050
Alta eficacia y robustez superior en un paquete de alta potencia con múltiples matrices, lo que permite un diseño de sistema rentable
Descripción
LUXEON Sun Plus 5050
LUXEON SunPlus 5050 es un LED robusto de alta potencia y múltiples matrices que utiliza un paquete de montaje en superficie 5050 estándar de la industria con una pequeña superficie emisora de luz (LES). LUXEON LUXEON SunPlus 5050 ofrece un rendimiento óptimo en μmol/J y PPF (μmol/s) y una larga vida útil con CCT que van de 1800 K a 6500 K y CRI de 70, 80 y 90. Ofrece orientación de colores cálidos para garantizar que los LED estén dentro del objetivo de color en condiciones de aplicación de 85 grados.
Características y beneficios
- Rendimiento óptimo en μmol/J y PPF (μmol/s)
- El diseño de paquete extremadamente confiable afirma una larga vida útil en entornos hash
Aplicaciones
- Horticultura
5050 piezas redondas
Rendimiento del producto LUXEON SunPlus 5050 a la corriente especificada, Tj=25 grado. La temperatura de color correlacionada es cálida y tiene como objetivo Tj=85 grados
| Voltaje | Nominal CCT |
Mínimo IRC |
FPP (umol/s) | PPF/W típico (umol/J) |
Número de pieza | |
|---|---|---|---|---|---|---|
| Mínimo | Típico | |||||
| 24V | 1800K | 70 | 6.25 | 7.01 | 1.80 | L150-1870502400000 |
| 2200K | 70 | 7.50 | 8.41 | 2.15 | L150-2270502400000 | |
| 2700K | 70 | 7.28 | 8.57 | 2.19 | L150-2770502400000 | |
| 3000K | 70 | 7.66 | 8.72 | 2.23 | L150-3070502400000 | |
| 3500K | 70 | 8.30 | 8.87 | 2.27 | L150-3570502400000 | |
| 4000K | 70 | 7.10 | 9.06 | 2.32 | L150-4070502400000 | |
| 5000K | 70 | 8.01 | 9.01 | 2.31 | L150-5070502400000 | |
| 5700K | 70 | 8.02 | 9.00 | 2.31 | L150-5770502400000 | |
| 6500K | 70 | 8.04 | 9.02 | 2.31 | L150-6570502400000 | |
| 2200K | 80 | 6.94 | 8.01 | 2.05 | L150-2280502400000 | |
| 2700K | 80 | 7.20 | 8.44 | 2.16 | L150-2780502400000 | |
| 3000K | 80 | 7.16 | 8.62 | 2.21 | L150-3080502400000 | |
| 3500K | 80 | 5.40 | 8.63 | 2.21 | L150-3580502400000 | |
| 4000K | 80 | 7.95 | 8.75 | 2.24 | L150-4080502400000 | |
| 5000K | 80 | 7.74 | 8.81 | 2.26 | L150-5080502400000 | |
| 5700K | 80 | 7.75 | 8.74 | 2.24 | L150-5780502400000 | |
| 6500K | 80 | 8.00 | 8.75 | 2.24 | L150-6580502400000 | |
| 2700K | 90 | 6.77 | 7.59 | 1.94 | L150-2790502400000 | |
| 3000K | 90 | 6.97 | 7.75 | 1.98 | L150-3090502400000 | |
| 3500K | 90 | 7.23 | 7.90 | 2.02 | L150-3590502400000 | |
| 4000K | 90 | 7.58 | 8.17 | 2.09 | L150-4090502400000 | |
| 5000K | 90 | 7.67 | 8.13 | 2.08 | L150-5090502400000 | |
| 5700K | 90 | 7.49 | 8.08 | 2.07 | L150-5790502400000 | |
| 6V | 1800K | 70 | 6.25 | 7.01 | 1.80 | L150-1870500600000 |
| 2200K | 70 | 7.50 | 8.41 | 2.15 | L150-2270500600000 | |
| 2700K | 70 | 7.28 | 8.57 | 2.19 | L150-2770500600000 | |
| 3000K | 70 | 7.66 | 8.72 | 2.23 | L150-3070500600000 | |
| 3500K | 70 | 8.30 | 8.87 | 2.27 | L150-3570500600000 | |
| 4000K | 70 | 7.10 | 9.06 | 2.32 | L150-4070500600000 | |
| 5000K | 70 | 8.01 | 9.01 | 2.31 | L150-5070500600000 | |
| 5700K | 70 | 8.02 | 9.00 | 2.31 | L150-5770500600000 | |
| 6500K | 70 | 8.04 | 9.02 | 2.31 | L150-6570500600000 | |
| 2200K | 80 | 6.94 | 8.01 | 2.05 | L150-2280500600000 | |
| 2700K | 80 | 7.20 | 8.44 | 2.16 | L150-2780500600000 | |
| 3000K | 80 | 7.16 | 8.62 | 2.21 | L150-3080500600000 | |
| 3500K | 80 | 5.40 | 8.63 | 2.21 | L150-3580500600000 | |
| 4000K | 80 | 7.95 | 8.75 | 2.24 | L150-4080500600000 | |
| 5000K | 80 | 7.74 | 8.81 | 2.26 | L150-5080500600000 | |
| 5700K | 80 | 7.75 | 8.74 | 2.24 | L150-5780500600000 | |
| 6500K | 80 | 8.00 | 8.75 | 2.24 | L150-6580500600000 | |
| 2700K | 90 | 6.77 | 7.59 | 1.94 | L150-2790500600000 | |
| 3000K | 90 | 6.97 | 7.75 | 1.98 | L150-3090500600000 | |
| 3500K | 90 | 7.23 | 7.90 | 2.02 | L150-3590500600000 | |
| 4000K | 90 | 7.58 | 8.17 | 2.09 | L150-4090500600000 | |
| 5000K | 90 | 7.67 | 8.13 | 2.08 | L150-5090500600000 | |
| 5700K | 90 | 7.49 | 8.08 | 2.07 | L150-5790500600000 | |
5050 piezas cuadradas
Rendimiento del producto LUXEON SunPlus 5050 a la corriente especificada, Tj=25 grado. La temperatura de color correlacionada es cálida y tiene como objetivo Tj=85 grados
| Voltaje | CCT nominales | IRC mínimo | FPP (umol/s) | PPF/W típico (umol/J) | Número de pieza | |
|---|---|---|---|---|---|---|
| Mínimo | Típico | |||||
| 30V | 1800K | 70 | 9.03 | 9.70 | 1.99 | L150-18705030000S0 |
| 2200K | 70 | 9.03 | 10.30 | 2.11 | L150-22705030000S0 | |
| 2700K | 70 | 9.36 | 10.60 | 2.17 | L150-27705030000S0 | |
| 3000K | 70 | 9.71 | 10.70 | 2.19 | L150-30705030000S0 | |
| 3500K | 70 | 9.53 | 10.80 | 2.21 | L150-35705030000S0 | |
| 4000K | 70 | 9.68 | 10.90 | 2.23 | L150-40705030000S0 | |
| 5000K | 70 | 9.69 | 11.00 | 2.25 | L150-50705030000S0 | |
| 5700K | 70 | 9.98 | 11.10 | 2.27 | L150-57705030000S0 | |
| 6500K | 70 | 9.56 | 11.00 | 2.25 | L150-65705030000S0 | |
| 2200K | 80 | 9.23 | 9.85 | 2.02 | L150-22805030000S0 | |
| 2700K | 80 | 9.29 | 9.97 | 2.04 | L150-27805030000S0 | |
| 3000K | 80 | 9.70 | 10.24 | 2.10 | L150-30805030000S0 | |
| 3500K | 80 | 9.25 | 10.12 | 2.07 | L150-35805030000S0 | |
| 4000K | 80 | 9.87 | 10.52 | 2.16 | L150-40805030000S0 | |
| 5000K | 80 | 9.93 | 10.66 | 2.18 | L150-50805030000S0 | |
| 5700K | 80 | 9.76 | 10.67 | 2.19 | L150-57805030000S0 | |
| 6500K | 80 | 10.26 | 10.59 | 2.17 | L150-65805030000S0 | |
| 2700K | 90 | 9.55 | 9.82 | 2.01 | L150-27905030000S0 | |
| 3000K | 90 | 9.48 | 10.09 | 2.07 | L150-30905030000S0 | |
| 3500K | 90 | 9.48 | 10.06 | 2.06 | L150-35905030000S0 | |
| 4000K | 90 | 9.81 | 10.16 | 2.08 | L150-40905030000S0 | |
| 5000K | 90 | 9.88 | 10.23 | 2.10 | L150-50905030000S0 | |
| 5700K | 90 | 9.87 | 10.28 | 2.11 | L150-57905030000S0 | |
| 6V | 1800K | 70 | 9.03 | 9.70 | 1.99 | L150-18705006000S0 |
| 2200K | 70 | 9.03 | 10.30 | 2.11 | L150-22705006000S0 | |
| 2700K | 70 | 9.36 | 10.60 | 2.17 | L150-27705006000S0 | |
| 3000K | 70 | 9.71 | 10.70 | 2.19 | L150-30705006000S0 | |
| 3500K | 70 | 9.53 | 10.80 | 2.21 | L150-35705006000S0 | |
| 4000K | 70 | 9.68 | 10.90 | 2.23 | L150-40705006000S0 | |
| 5000K | 70 | 9.69 | 11.00 | 2.25 | L150-50705006000S0 | |
| 5700K | 70 | 9.98 | 11.10 | 2.27 | L150-57705006000S0 | |
| 6500K | 70 | 9.56 | 11.00 | 2.25 | L150-65705006000S0 | |
| 2200K | 80 | 9.23 | 9.85 | 2.02 | L150-22805006000S0 | |
| 2700K | 80 | 9.29 | 9.97 | 2.04 | L150-27805006000S0 | |
| 3000K | 80 | 9.70 | 10.24 | 2.10 | L150-30805006000S0 | |
| 3500K | 80 | 9.25 | 10.12 | 2.07 | L150-35805006000S0 | |
| 4000K | 80 | 9.87 | 10.52 | 2.16 | L150-40805006000S0 | |
| 5000K | 80 | 9.93 | 10.66 | 2.18 | L150-50805006000S0 | |
| 5700K | 80 | 9.76 | 10.67 | 2.19 | L150-57805006000S0 | |
| 6500K | 80 | 10.26 | 10.59 | 2.17 | L150-65805006000S0 | |
| 2700K | 90 | 9.55 | 9.82 | 2.01 | L150-27905006000S0 | |
| 3000K | 90 | 9.48 | 10.09 | 2.07 | L150-30905006000S0 | |
| 3500K | 90 | 9.48 | 10.06 | 2.06 | L150-35905006000S0 | |
| 4000K | 90 | 9.81 | 10.16 | 2.08 | L150-40905006000S0 | |
| 5000K | 90 | 9.88 | 10.23 | 2.10 | L150-50905006000S0 | |
| 5700K | 90 | 9.87 | 10.28 | 2.11 | L150-57905006000S0 | |
Piezas 5050 HE
Rendimiento del producto LUXEON SunPlus 5050 a la corriente especificada, Tj=25 grado. La temperatura de color correlacionada es cálida y tiene como objetivo Tj=85 grados
| Voltaje | Nominal CCT |
Mínimo IRC |
FPP (umol/s) | PPF/W típico (umol/J) |
Número de pieza | |
|---|---|---|---|---|---|---|
| Mínimo | Típico | |||||
| 24V | 1800K | 70 | 7.30 | 8.04 | 2.08 | L150-18705024000H0 |
| 2200K | 70 | 8.06 | 8.67 | 2.24 | L150-22705024000H0 | |
| 2700K | 70 | 8.38 | 8.94 | 2.31 | L150-27705024000H0 | |
| 3000K | 70 | 8.29 | 9.09 | 2.35 | L150-30705024000H0 | |
| 3500K | 70 | 8.21 | 9.28 | 2.40 | L150-35705024000H0 | |
| 4000K | 70 | 8.42 | 9.37 | 2.42 | L150-40705024000H0 | |
| 5000K | 70 | 8.61 | 9.47 | 2.45 | L150-50705024000H0 | |
| 5700K | 70 | 9.00 | 9.51 | 2.46 | L150-57705024000H0 | |
| 6500K | 70 | 8.58 | 9.62 | 2.48 | L150-65705024000H0 | |
| 2200K | 80 | 7.51 | 8.15 | 2.10 | L150-22805024000H0 | |
| 2700K | 80 | 7.84 | 8.52 | 2.20 | L150-27805024000H0 | |
| 3000K | 80 | 7.66 | 8.73 | 2.25 | L150-30805024000H0 | |
| 3500K | 80 | 8.09 | 8.92 | 2.30 | L150-35805024000H0 | |
| 4000K | 80 | 8.18 | 8.97 | 2.32 | L150-40805024000H0 | |
| 5000K | 80 | 8.42 | 9.01 | 2.33 | L150-50805024000H0 | |
| 5700K | 80 | 8.29 | 9.07 | 2.34 | L150-57805024000H0 | |
| 6500K | 80 | 8.58 | 9.11 | 2.35 | L150-65805024000H0 | |
| 2700K | 90 | 7.73 | 8.20 | 2.12 | L150-27905024000H0 | |
| 3000K | 90 | 7.92 | 8.28 | 2.14 | L150-30905024000H0 | |
| 3500K | 90 | 8.11 | 8.42 | 2.18 | L150-35905024000H0 | |
| 4000K | 90 | 8.14 | 8.58 | 2.22 | L150-40905024000H0 | |
| 5000K | 90 | 8.36 | 8.77 | 2.26 | L150-50905024000H0 | |
| 5700K | 90 | 8.31 | 8.79 | 2.27 | L150-57905024000H0 | |
| 1800K | 70 | 7.30 | 8.00 | 2.07 | L150-1870502400TH0 | |
| 2200K | 70 | 8.06 | 8.63 | 2.23 | L150-2270502400TH0 | |
| 2700K | 70 | 8.38 | 8.90 | 2.30 | L150-2770502400TH0 | |
| 3000K | 70 | 8.29 | 9.04 | 2.34 | L150-3070502400TH0 | |
| 3500K | 70 | 8.21 | 9.23 | 2.38 | L150-3570502400TH0 | |
| 4000K | 70 | 8.42 | 9.32 | 2.41 | L150-4070502400TH0 | |
| 5000K | 70 | 8.61 | 9.42 | 2.43 | L150-5070502400TH0 | |
| 5700K | 70 | 9.00 | 9.46 | 2.44 | L150-5770502400TH0 | |
| 6500K | 70 | 8.58 | 9.57 | 2.47 | L150-6570502400TH0 | |
| 2200K | 80 | 7.51 | 8.09 | 2.09 | L150-2280502400TH0 | |
| 2700K | 80 | 7.84 | 8.40 | 2.17 | L150-2780502400TH0 | |
| 3000K | 80 | 7.66 | 8.62 | 2.23 | L150-3080502400TH0 | |
| 3500K | 80 | 8.09 | 8.83 | 2.28 | L150-3580502400TH0 | |
| 4000K | 80 | 8.18 | 8.98 | 2.32 | L150-4080502400TH0 | |
| 5000K | 80 | 8.42 | 9.03 | 2.33 | L150-5080502400TH0 | |
| 5700K | 80 | 8.29 | 9.05 | 2.34 | L150-5780502400TH0 | |
| 6500K | 80 | 8.58 | 9.09 | 2.35 | L150-6580502400TH0 | |
| 2700K | 90 | 7.73 | 8.20 | 2.12 | L150-2790502400TH0 | |
| 3000K | 90 | 7.92 | 8.28 | 2.14 | L150-3090502400TH0 | |
| 3500K | 90 | 8.11 | 8.42 | 2.18 | L150-3590502400TH0 | |
| 4000K | 90 | 8.14 | 8.58 | 2.22 | L150-4090502400TH0 | |
| 5000K | 90 | 9.36 | 8.77 | 2.26 | L150-5090502400TH0 | |
| 5700K | 90 | 8.31 | 8.79 | 2.27 | L150-5790502400TH0 | |
| 6V | 1800K | 70 | 7.30 | 8.04 | 2.08 | L150-18705006000H0 |
| 2200K | 70 | 8.06 | 8.67 | 2.24 | L150-22705006000H0 | |
| 2700K | 70 | 8.38 | 8.94 | 2.31 | L150-27705006000H0 | |
| 3000K | 70 | 8.29 | 9.09 | 2.35 | L150-30705006000H0 | |
| 3500K | 70 | 8.21 | 9.28 | 2.40 | L150-35705006000H0 | |
| 4000K | 70 | 8.42 | 9.37 | 2.42 | L150-40705006000H0 | |
| 5000K | 70 | 8.61 | 9.47 | 2.45 | L150-50705006000H0 | |
| 5700K | 70 | 9.00 | 9.51 | 2.46 | L150-57705006000H0 | |
| 6500K | 70 | 8.58 | 9.62 | 2.48 | L150-65705006000H0 | |
| 2200K | 80 | 7.51 | 8.15 | 2.10 | L150-22805006000H0 | |
| 2700K | 80 | 7.84 | 8.52 | 2.20 | L150-27805006000H0 | |
| 3000K | 80 | 7.66 | 8.73 | 2.25 | L150-30805006000H0 | |
| 3500K | 80 | 8.09 | 8.92 | 2.30 | L150-35805006000H0 | |
| 4000K | 80 | 8.18 | 8.97 | 2.32 | L150-40805006000H0 | |
| 5000K | 80 | 8.42 | 9.01 | 2.33 | L150-50805006000H0 | |
| 5700K | 80 | 8.29 | 9.07 | 2.34 | L150-57805006000H0 | |
| 6500K | 80 | 8.58 | 9.11 | 2.35 | L150-65805006000H0 | |
| 2700K | 90 | 7.73 | 8.20 | 2.12 | L150-27905006000H0 | |
| 3000K | 90 | 7.92 | 8.28 | 2.14 | L150-30905006000H0 | |
| 3500K | 90 | 8.11 | 8.42 | 2.18 | L150-35905006000H0 | |
| 4000K | 90 | 8.14 | 8.58 | 2.22 | L150-40905006000H0 | |
| 5000K | 90 | 8.36 | 8.77 | 2.26 | L150-50905006000H0 | |
| 5700K | 90 | 8.31 | 8.79 | 2.27 | L150-57905006000H0 | |
| 1800K | 70 | 7.30 | 8.00 | 2.07 | L150-1870500600TH0 | |
| 2200K | 70 | 8.06 | 8.63 | 2.23 | L150-2270500600TH0 | |
| 2700K | 70 | 8.38 | 8.90 | 2.30 | L150-2770500600TH0 | |
| 3000K | 70 | 8.29 | 9.04 | 2.34 | L150-3070500600TH0 | |
| 3500K | 70 | 8.21 | 9.23 | 2.38 | L150-3570500600TH0 | |
| 4000K | 70 | 8.42 | 9.32 | 2.41 | L150-4070500600TH0 | |
| 5000K | 70 | 8.61 | 9.42 | 2.43 | L150-5070500600TH0 | |
| 5700K | 70 | 9.00 | 9.46 | 2.44 | L150-5770500600TH0 | |
| 6500K | 70 | 8.58 | 9.57 | 2.47 | L150-6570500600TH0 | |
| 2200K | 80 | 7.51 | 8.09 | 2.09 | L150-2280500600TH0 | |
| 2700K | 80 | 7.84 | 8.40 | 2.17 | L150-2780500600TH0 | |
| 3000K | 80 | 7.66 | 8.62 | 2.23 | L150-3080500600TH0 | |
| 3500K | 80 | 8.09 | 8.83 | 2.28 | L150-3580500600TH0 | |
| 4000K | 80 | 8.18 | 8.98 | 2.32 | L150-4080500600TH0 | |
| 5000K | 80 | 8.42 | 9.03 | 2.33 | L150-5080500600TH0 | |
| 5700K | 80 | 8.29 | 9.05 | 2.34 | L150-5780500600TH0 | |
| 6500K | 80 | 8.58 | 9.09 | 2.35 | L150-6580500600TH0 | |
| 2700K | 90 | 7.73 | 8.20 | 2.12 | L150-2790500600TH0 | |
| 3000K | 90 | 7.92 | 8.28 | 2.14 | L150-3090500600TH0 | |
| 3500K | 90 | 8.11 | 8.42 | 2.18 | L150-3590500600TH0 | |
| 4000K | 90 | 8.14 | 8.58 | 2.22 | L150-4090500600TH0 | |
| 5000K | 90 | 8.36 | 8.77 | 2.26 | L150-5090500600TH0 | |
| 5700K | 90 | 8.31 | 8.79 | 2.27 | L150-5790500600TH0 | |
5050 HE Plus Piezas
Rendimiento del producto LUXEON SunPlus 5050 HE Plus a la corriente especificada, Tj=25 grado. La temperatura de color correlacionada es cálida y tiene como objetivo Tj=85 grados
| Voltaje | Nominal CCT |
Mínimo IRC |
FPP (umol/s) | PPF/W típico (umol/J) |
Número de pieza | |
|---|---|---|---|---|---|---|
| Mínimo | Típico | |||||
| 6V | 1800K | 70 | 8.15 | 8.41 | 2.25 | L150-1870500600HH0 |
| 2200K | 70 | 8.62 | 9.07 | 2.42 | L150-2270500600HH0 | |
| 2700K | 70 | 8.65 | 9.26 | 2.47 | L150-2770500600HH0 | |
| 3000K | 70 | 8.94 | 9.31 | 2.49 | L150-3070500600HH0 | |
| 3500K | 70 | 8.74 | 9.36 | 2.50 | L150-3570500600HH0 | |
| 4000K | 70 | 9.15 | 9.61 | 2.57 | L150-4070500600HH0 | |
| 5000K | 70 | 9.27 | 9.68 | 2.59 | L150-5070500600HH0 | |
| 5700K | 70 | 9.18 | 9.62 | 2.57 | L150-5770500600HH0 | |
| 6500K | 70 | 9.30 | 9.81 | 2.62 | L150-6570500600HH0 | |
| 2200K | 80 | 7.79 | 8.36 | 2.23 | L150-2280500600HH0 | |
| 2700K | 80 | 8.49 | 8.93 | 2.39 | L150-2780500600HH0 | |
| 3000K | 80 | 8.29 | 8.98 | 2.40 | L150-3080500600HH0 | |
| 3500K | 80 | 8.75 | 9.12 | 2.44 | L150-3580500600HH0 | |
| 4000K | 80 | 8.98 | 9.36 | 2.50 | L150-4080500600HH0 | |
| 5000K | 80 | 9.08 | 9.37 | 2.50 | L150-5080500600HH0 | |
| 5700K | 80 | 8.84 | 9.39 | 2.51 | L150-5780500600HH0 | |
| 6500K | 80 | 8.84 | 9.50 | 2.54 | L150-6580500600HH0 | |
Etiqueta: luxeon sunplus 5050, China luxeon sunplus 5050 fabricantes, proveedores, fábrica, L1CU-40800000000, L1CU-LME1000000000, L1CU-RED1000000000, L1SP-frd0002000000, L1SP-RYL0002000000, L2C4-3090-M03E0900
Artículo anterior:Gama de núcleos CoB LUXEON
Siguiente artículo:LUXEON Sun Plus 3030
Envíeconsulta
También podría gustarte
